BZ482 SD - 13,5bhp


BZ482 SD - 13,5bhp
 Technical Data
  No. of cylinders 2
  Swept volume 478 cc
  Bore 67 mm
  Stroke 68 mm
  Nett weight with gearbox 86 kg

 Power Output
  rpm bhp
  3000 13.5
beta ten power curve

This engine has been specifically developed for installation in motor cruisers, heavy duty commercial fishing boats, launches and barges where an engine is required with high torque at low r.p.m. Based on the Ford/Iveco 7.5 litre engine, this Beta engine will operate very smoothly over the speed range. Competitive prices and very low fuel consumption make them excellent value for money.

STANDARD SPECIFICATIONS

  • Heat exchanger cooled diesel engine with header tank, indirect injection, naturally aspirated, based on Kubota.
  • Smooth running with multi-cylinder and high inertia flywheel.
  • Water cooled exhaust manifold.
  • Fresh and sea water pumps
  • Three vortex combustion for quiet running, low emissions and excellent fuel consumption
  • 12 volt electric starting with 40 amp battery charging alternator.
  • Heater plugs for cold start below 5°C.
  • Control Panel type ABV as standard with 3 metre interconnection cable and multi pin plug and socket.
  • GRP base for "glassing" into the hull and flexible engine mountings.
  • Engine with heat exchanger and header tank
  • Fuel filter and mechanical fuel lift pump.
  • Lubricating oil filter and sump drain pump.
  • Saildrive 2.2 : 1 reduction
  • Morse type cable support and end fittings for engine speed and gearbox control.
  • Engine test certificate and operators manual.

OPTIONS

a panel
  • Deluxe C Control panel
  • 65 amp alternator (in lieu of 40 amp).
  • 2 blade folding propeller.
